Gallery


Duplicating Molded Part

Duplicating Molded Part

Boat owner needed obsolete plastic parts duplicated.

Five Axis Single Setup

Five Axis Single Setup

Five axis machined from a solid block of Delrin. All without moving part in vise.

CMC Mill with Parts Probe

CMC Mill with Parts Probe

Maskinell's CNC custom operations on Haas. 40" x 26" x 25" capacity.

CMMs in Office

CMMs in Office

CMM - Computerized Measuring Machines. Used to verify parts are made correctly.

EDM in Brass

EDM in Brass

Electrical Discharge Machining in Brass makes for a laser effect, but this is just sparks jumping from a wire to the brass.

Hot Part

Hot Part

Heat treating a small part.

OD_Grinder

OD_Grinder

Grinding long shaft. Red stripes checks for roundness of part.

Tesla_motor

Tesla_motor

Measuring a Tesla motor.

Turnings_drying

Turnings_drying

An order for a few hundred simple round turnings. These are drying after washing.

Radar_Brake

Radar_Brake

Large aluminum part replacing casting from 1959. Reverse engineered by Maskinell. CMM verified.

Copper Parts

Copper Parts

Copper parts to accurately mount thermocouple.

Laser Welding

Laser Welding

A CNC machining blemish welded with laser for remachining.

Coolant shower inside a Mill

Coolant shower inside a Mill

Flood coolant allows for rapid machining.

Big Material

Big Material

A 400 lb piece of stainless steel being loaded into our saw. A 6" Diameter shaft.

Jet Engine Component Tools

Jet Engine Component Tools

We make specialty tools to work on aircraft engines. These had a very special treading requirement.

Wood Strut

Wood Strut

This strut we made out of Ashe per British specifications. Red paint was part of the spec.

TuftRide Coated tool

TuftRide Coated tool

Special coatings make surfaces very hard or wear resistant, as is the case here.

Surface Grinding

Surface Grinding

Surface grinding is a very accurate way to take .0001" off of flat surfaces. It is excellent for insuring surfaces are parallel.

Tool Components

Tool Components

Company had lost some pieces so we built replacements.

EDM Electrical Discharge Machining

EDM Electrical Discharge Machining

EDM uses sparks to remove metal. Sort of reverse welding, but engineers would call it rapid corrosion. Typically 10 times more precise than traditional machining.

Artsy Machining

Artsy Machining

Intriguing cubes made from brass and aluminum.

Base for Turbine Repair

Base for Turbine Repair

A large project. This is a shop base to set some jet turbine components on. Many little clips around the edge.

Nylon Rail Guides

Nylon Rail Guides

Nylon rail guides made for an emergency job.

Tool Cart

Tool Cart

Some of the numerous tools for our CNC Mill

Fixture For Automotive

Fixture For Automotive

Fixture to verify automotive trim part.
